Aluminium right angle gearboxes ZL
Our ZL series right angle gears are not heavy and are silent functioning.
The one house piece in aluminium is strong, the gears are Gleason and the bearings are overrated as well.
The backlash is 15’-30’ and they are filled with lubricant for all the mounting positions.
These right angle gears are available with 3 fixing flange, 3 or 4 locking through holes on the body, 2 or 3 shafts and ratio 1-2-3.
Main features
Strength and solidity
Excellent weight/power ratio
Specifications
-
Ratio
Min 1/1 - Max 1/2
-
Torque (Nm)
Min 1,1 - Max 42
-
Power (Kw)
Min 0,08 - Max 6,5
